Vertical · Architecture & Specialist PlanningFrom PDF to Answer Machine
How a 14-person firm closes the gap between CAD office and construction site — before the building authority has to ask.
Authority correction requests 5 → 1Per permit procedure, thanks to rule checks run before submission.
Plan version errors on site ≈ 0Read confirmation on every delivery, plus a QR code showing whether a paper plan is current.
Site survey, apartment building ½ day was 2 daysiPhone LiDAR point clouds become editable walls in Studio, then carry into CAD.
Rule findings caught early 2 of 2Both resolved before permit planning — none arriving as an authority’s demand.
“We keep drawing in CAD. But the questions the authority used to ask are now asked by our own model — beforehand.” — Partner, Nordlicht Architekten (fictional case study)What Studio checks before submission: ⅛ window-to-floor area ratios · rescue windows · accessibility per DIN 18040 · clear heights — each finding with cited references. What Cloud fixes on site: revision diffs from index C to D in seconds, ending the “I had the old plan” excuse.
An architecture firm uses Gewerkton Studio as an extended arm on the construction site — and lets the model answer the questions that building inspection would otherwise ask.
As an affiliate, we earn on qualifying purchases.
The Company
The fictional firm Nordlicht Architekten, 14 people, residential and educational buildings. CAD remains the authoring tool — but between the office and the construction site yawned a PDF-shaped gap.
The Starting Point
Outdated plan revisions circulated on the construction site; site management queries arrived as cell phone photos with scribbled circles; and whether a children’s bedroom window met escape route dimensions was checked three times by hand — or, in the worst case, by the building authority.
Cloud: Plan Distribution with Proof
Every plan delivery goes to the distribution list with read confirmation; the revision diff shows site management in seconds what changed from index C to D. “I had the old plan” is abolished as an excuse — the QR code in the plan header tells any paper plan whether it is still current.
Studio: Rule Checking Before Submission
⅛ window-to-floor area ratios, rescue windows, accessibility per DIN 18040, clear heights: the rule engine checks the design with cited references. Two findings in the scenario — both resolved before permit planning instead of arriving as an authority’s demand for corrections.
Existing Structures: Scan, Don’t Estimate
For renovations, the firm captures the existing structure using iPhone LiDAR and point clouds; Studio turns them into editable walls, which the CAD system takes over for detailed design. The site survey, formerly two days with laser and notepad, now takes one morning.
The Figures from the Scenario
– Building authority correction requests: from 5 to 1 per procedure (rule checks in advance) – Plan version errors on the construction site: near zero — read confirmation + QR check – Site survey of an apartment building: 1 morning instead of 2 days
“We keep drawing in CAD. But the questions the authority used to ask are now asked by our own model — beforehand.”
—
Fictional case study: The company, individuals, and figures are invented and serve for illustration purposes. The basis is the target build-out of the Gewerkton platform (Field, Studio, Cloud, Archive, Betrieb). Gewerkton is a voice-first platform for construction documentation and defect management for global markets — with the deepest integration into German construction standards (GAEB, REB, XRechnung, DATEV), 27 content languages, and regional AI provider choice.
