Eurorack Studio Command Center
A centerpiece to any electronic composer and producer studio, the Structure 344 merges a classic form with robust power and deep, integrated synthesis tools. The 4 row, 344 hp desktop eurorack case features a custom Utility Bridge to handle a wide assortment of functions incorporating a preamp, mixer/splitter, dual voltage controlled signal buses, buffered, cascading attenuators, and more.
Structure 344 Enclosure details
- Four 86hp Rows
- 344hp Total Space Available
- Multi-Functional Integrated Audio and CV Utility Hub
- Edge to Edge, Through Wall Mounted Rails Reduce Gaps Between Modules and the Side of the Case
- Full Row Nut Strips
- Includes 160 Black (Size M3 6mm) Module Mounting Screws
- Beautifully Hand-Stained Hardwood
Structure 344 Utility Bridge details
- Soft Clipping Overdriveable Pre-Amp
- Fully Buffered 2 In – 4 Out Unity Gain Mixer/Splitter
- Dual Voltage Controlled Bus System with Each Bus Incorporating a 3 Channel Mixer with Offset, Inversion, Breakout Channels and More.
- 6 Assignable Bus Outputs.
- Bus Mixers Featuring And (mix) Output, Analog Or Output, And Inverted Mix Output
- Dual Fully Buffered Cascading Attenuators
Structure 344 Power details
- Up to 5 Amps of Clean, Filtered +12v Power
- 5 Amps of Clean, Filtered -12v Power
- Up to 3 Amps of Clean, Filtered +5v Power (see manual for detailed power breakdown)
- 79 Keyed 16 Pin Eurorack Power Headers
- Rear Mounted Power Switch with LED
- Fused Power Protection
- Universal IEC Power Connector
- 2 EMI Filters Protect All 3 Power Rails (+12v, +5v, -12v)
- Low Output Ripple & Noise
- UL & CE Approved, RoHS Compliant
- Over Load and Short Circuit Protection
- Line Regulation (Full Load): ≤0.5%
- Output Over Load Protection: 10%-150% Hiccup Mode with Auto-Recovery
Structure 344 Dimensions
- External Depth at Top: 4”
- External Depth at Base: 15.5”
- External Height: 19”
- External Width: 18”
- Maximum Internal Depth for Modules: 4”
- Empty Weight: 19.5 lbs
